ABB S800 User Manual

Support for HART Communication Section 2 Product Description
58 3BSE015969-600 A
to S800 I/O via the TU812 termination unit which provides a D-sub connector. For
further information, refer the link www.s800connection.com.
Support for HART Communication
S800 I/O provides possibilities to communicate via HART protocol with HART
Field Devices via PROFIBUS-DPV1 using CI840 or CI801 or AF100 using CI810
or CI820. There are four I/O modules that have HART interface, AI815, AI845,
AO815, AO845, AO845A, AI895 and AO895.
For HART connection via external HART MUX, see Support for connections to
instruments in Hazardous Areas on page 55.
S800 I/O provides the possibilities for HART communication, but the user
function is defined by the system (operator stations and controllers) S800 I/O is
included in. Always read the relevant system documentation for information
about the supported features and needed components of S800 I/O.
On PROFIBUS, an Extended HART mode gives a possibility to pass-through
long HART data frames up to 227 bytes. This will reduce the possible amount of
I/O modules per station. The longest HART data frame without the Extended
HART mode is 64 bytes.

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
