ABB S800 User Manual

Supported I/O Modules and Drives via PROFIBUS and CI840 Section 3 Technical Data and
160 3BSE015969-600 A
– ACS600/ACS800/DCS600 with crane application
– ACS600/ACS800 with pump and fan application (PFC)
– ACS400/DCS500/DCS400 with standard drive
Supported I/O Modules and Drives via PROFIBUS and
CI840
The following I/O modules are supported by the PROFIBUS Field
Communication Interface module CI840. Check the controller documentation for
information about I/O module support implemented in the controller:
• AI801, AI810, AI815, AI820, AI825, AI830, AI830A, AI835, AI843, AI845,
AI890, AI893, AI895
• AO801, AO810, AO815, AO810V2, AO820, AO845, AO845A, AO890,
AO895
• DI801, DI802, DI803, DI810, DI811, DI814, DI818, DI820, DI821, DI828,
DI825
1
, DI830
1
, DI831
1
, DI840 (SOE handling not supported), DI885
1
, DI890
• DO801, DO802, DO810, DO814, DO815, DO818, DO820, DO821, DO828,
DO840, DO890
• DP820, DP840
1. Not supported by AC 800M

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
