Support for Externally Connected Accessories Section 2 Product Description
56 3BSE015969-600 A
Support for Externally Connected Accessories
Connection to External Intrinsic Safety System
The Intrinsic Safety System from Pepperl+Fuchs (manufacturer outside ABB)
is supported via S800 I/O modules and a special MTU.
The supported Intrinsic Safety System is the HiD Series 2000.
The S800 I/O modules are connected via MTU TU812/TU812V1, a standard cable
from Pepperl+Fuchs and a specific adapter board, one for each I/O module types
according to Table 8. The standards of cables - 0.2 m (0.66 ft) and 1.3 m (4.3 ft).
The maximum cable length is 100 m (109 yd).
Table 8. Supported Modules and Intrinsic Safety Components
ABB delivery Pepperl+Fuchs delivery
S800 I/O
module
Terminal
unit
Termination and adaptor
board
Intrinsic Safety
modules
Note
AI810 TU812 2108/HAT/ABB-AI-H-01 2026, 2030, 2062, 2072 Dual channel
modules
2108/HAKE/ABB-AI-H-01
(1)
(1) Loop-disconnected terminals
2026, 2030 using
passive connection
Dual channel
modules
AO810/
AO810V2
TU812 2108/HAT/ABB-AO-H-01 2032, 2034, 2038 Dual channel
modules
2108/HAKE/ABB-AO-H-01
(1)
2032, 2034, 2038 Dual channel
modules
DI810 TU812 2108/HAT/ABB-DI-01 2824, 2844 Quad channel
modules
DO810 TU812 2108/HAT/ABB-DO-01 2872, 2874, 2876, 2878 Dual channel
modules
2108/HAKE/ABB-DO-H-01
(1)
2872, 2874, 2876, 2878 Dual channel
modules

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
