ABB SGF User Manual

19. List of Item Numbers
19.1 Item Numbers
Note : The numbers in parentheses in the "Remarks" column are also item numbers. These numbers
also appear as item numbers in the first column in the list.
No. Description Remarks
1 Foundation, supporting structure, support Onsite
2 Disconnector base
3 Connecting lever Coupling of disconnector
5 Contact-side current path -
6 Finger-side current path -
7 Corona-protection fittings Only for rated voltages > 245 kV
11 Catching hook Contact-finger holder
12 Fixing device for Corona-protection fittings Only for rated voltages > 245 kV
13 Stud bolt Rotary pedestal (70)
15 Coupling rod Disconnector, earthing switch, series arrangement
17 High-voltage terminal Rotary pedestal (284)
18 Earthing contact Current path (5, 6)
19 Earthing-switch lever Earthing-switch shaft (73)
20 Contact finger Earthing-switch
21 Stop Earthing contact (18)
23 Tubular contact arm Earthing switch
26 Interlocking hook Finger side current path (6)
27 Interlocking bolt Contact-side current path (5)
36 Motor-operated mechanism -
37 Operating rod Disconnector
39 Emergency hand crank Motor-operated mechanism (36)
42 Pivot bearing Separate mounting of operating mechanism
43 Operating shaft Separate mounting of operating mechanism
55 Manual operating mechanism -
66 Contact finger Finger-side current path (6)
67 Contact piece Contact-side current path (5)
68 Diagonal rod Disconnector base (2)
69 Disconnector operating lever for operating Disconnector base (2)
mechanism
70 Rotary pedestal Disconnector base (2)
71 Operating rod Earthing switch
73 Earthing - switch shaft with Earthing-switch Earthing switch, series arrangement
lever (339)
74 Operating lever Operating mechanism for disconnector (75)
75 Operating mechanism for disconnector -
76 Operating lever Operating mechanism for earthing switch (77)
77 Operating mechanism for earthing switch -
79 Earthing connection Earthing switch
81 Fixing bolt Contact-finger holder, current path (6)
83 Operating rod Laterally offset mounting of operating mechanism
87 Corona-protection fittings Only for rated voltage = 300 kV
101 Fixing bolt Current path (5, 6)
152 Clamp sleeve 13 x 70 Operating rod (83)
153 Threaded pin M10 x 20 Collared bush (390)
201 Support insulator -
221 Base frame Disconnector base (2)
228 Earthing switch -
284 Rotary head Current path (5, 6)
289 Coupling / operating lever Earthing switch, contact side (CS), rat,
voltages 245 ... 300 kV
328 Transportation angle Base frame (221)
93/113
1HDB 050016-YN-A
