19.2 Connecting Sets
Connecting sets are included in the scope of supply. If necessary, connecting sets can be re-ordered
from us.
Order Information
To ensure speedy processing of your order, we need to know the item number and the order number of
the connecting set you require. Please find below the scope and the necessary order information for
the individual connecting sets :
Item No. 400, Order No. : GPDT 06 0001 R3
Connecting set, disconnector pole with IEC support insulators
Items No. Description Size Qty. Standard
400-302 Hexagon screw M16x30 DIN 933 8.8-tzn
400-321 Hexagon nut M16 8 DIN 934 A2-70
400-342 Washer A17 16 DIN 125 A2-70
Item No. 401, Order No. GPDT 06 0001 R1
Connecting set, disconnector pole with DIN support insulators
Items No. Description Size Qty. Standard
401-301 Hexagon screw M12x25 8 DIN 933 A2-70
401-321 Hexagon nut M16 8 DIN 934 A2-70
401-341 Washer A13 8 DIN 125 A2-70
401-342 Washer A17 8 DIN 125 A2-70
Item No. 410, Order No. : GPDT 06 0005 R50
Connecting set, coupling, disconnector and earthing switch
1 x for parallel arrangement, 2-pole (disconnector only)
2 x for parallel arrangement, 3-pole (disconnector only)
1 x for series arrangement, 2-pole
2 x for series arrangement, 3-pole
Item No. Description Size Qty. Standard
401-304 Hexagon screw M16x60 2 DIN 9338.8-tzn
410-324 Hexagon nut BM16 2 DIN 439 A2-70
410-325 Lock nut VM16 2 DIN 980 A2-70
410-340 Washer A17 4 DIN 125 A2-70
Item No. 420, Order No. : GPDT 06 0004 R50
Connecting set, (motor-operated) mechanism, disconnector
(mounting, operating mechanism and operating linkage)
Item No. Description Size Qty. Standard
420-303 Hexagon screw M16x60 1 DIN 933 8.8-tnz
420-306 Hexagon screw M16x30 2 DIN 933 8.8-tnz
420-309 Hexagon screw M16x80 1 DIN 933 8.8-tnz
420-320 Hexagon nut M16 2 DIN 934 8-tnz
420-323 Hexagon nut BM16 1 DIN 439 A2-70
420-325 Lock nut VM16 2 DIN 980 A2-70
420-340 Washer A17 6 DIN 125 A2-70
95/113
1HDB 050016-YN-A
