Acer Aspire 4930 Series Service Guide

Chapter 3 141
Replacing the Touch Pad
IMPORTANT:The Touch Pad cannot be removed individually. To replace the Touch Pad, replace the
entire Upper Cover.
1. Replace the Touch Pad bracket. 2. Replace the two securing screws from the Touch
Pad bracket.
3. Replace the Finger Print reader FFC and secure
with the adhesive strips.
4. Replace the Touch Pad FFC and secure with the
adhesive strips.
5. Connect the Touch Pad cable to the Touch Pad board.

Acer Aspire 4930 Series Specifications

General

Memory	Up to 4 GB DDR2
Battery Life	Up to 3 hours
Processor	Intel Core 2 Duo
Display	1280x800 resolution
Graphics	Intel GMA 4500MHD
Storage	320GB HDD
Optical Drive	DVD Super Multi
Operating System	Windows Vista
Battery	6-cell Li-ion
Weight	2.4 kg
Wireless	802.11a/b/g/n
