Chapter 1 31
Hardware Specifications and Configurations
Processor
CPU Fan True Value Table
• Throttling 50%: On= 100°C; OFF=90°C
• OS shut down at 105°C; H/W shut down at 96°C
BIOS
Item Specification
CPU type Intel® Core™2 Duo mobile processor, supporting Intel® 64
architecture
Core logic Mobile Intel® GM45/PM45 + ICH9M
CPU package Socket M (FCPGA6)
CPU core voltage 1.0375V to 1.3V
CPU Temperature
Fan Speed (rpm) SPL Spec (dBA)
Core 0 Core 1
58 58 2500 29
66 66 3000 31
74 74 3400 34
85 85 3800 37
100 100 4200 40
Item Specification
BIOS vendor Insyde
BIOS Version 1.00 (MP version)
BIOS ROM type Macronix_MX25L8005/ EON_EN25F80
BIOS ROM size 1M bytes
BIOS package SPI Flash part
Supported protocols ACPI 1.0b/2.0/3.0
PCI 2.2 or later
System/HDD Password Security Control
INT 13h Extensions
PnP BIOS 1.0a
SMBIOS 2.4 or later·
BIOS Boot Specification (Compal, Phoenix, Intel)
Simple Boot Flag 1.0
Boot Block
PCI Bus Power Management Interface Specification
USB Specification 1.1/2.0
USB Boot Up support
Support HD audio
WfM 2.0
Preboot Execution Environment (PXE) 2.1
Boot Integrity Service Application Program Interface (BIS) 1.0·
PC2002/2005 compliant
Intel Enhanced SpeedStep Technology
AHCI support.
BIOS password control Set by setup manual
