Acer Aspire 4930 Series Service Guide

Chapter 3 145
Replacing the Switch Cover
Replacing the WLAN Module
1. Connect the Switch Cover FFC as shown. 2. Replace the Switch cover, and press down to
secure in place.
3. Turn the computer over and replace the two securing screws.
1. Insert the WLAN board into the WLAN socket. 2. Replace the two screws to secure the module.

Acer Aspire 4930 Series Specifications

General

Memory	Up to 4 GB DDR2
Battery Life	Up to 3 hours
Processor	Intel Core 2 Duo
Display	1280x800 resolution
Graphics	Intel GMA 4500MHD
Storage	320GB HDD
Optical Drive	DVD Super Multi
Operating System	Windows Vista
Battery	6-cell Li-ion
Weight	2.4 kg
Wireless	802.11a/b/g/n
