Acer Aspire 4930 Series Service Guide

88 Chapter 3
Removing the Touch Pad Bracket
1. See “Removing the Battery Pack” on page 60.
2. See “Removing the SD dummy card” on page 61.
3. See “Removing the ExpressCard dummy card” on page 62.
4. See “Removing the Lower Covers” on page 63.
5. See “Removing the DIMM Module” on page 65.
6. See “Removing the WLAN Board Module” on page 66.
7. See “Removing the Hard Disk Drive Module” on page 68.
8. See “Removing the Optical Drive Module” on page 70.
9. See “Removing the Keyboard” on page 76.
10. See “Removing the LCD Module” on page 82.
11. See “Removing the Upper Cover” on page 84.
12. Disconnect the Touch Pad cable from the Touch Pad board.

Acer Aspire 4930 Series Specifications

General

Memory	Up to 4 GB DDR2
Battery Life	Up to 3 hours
Processor	Intel Core 2 Duo
Display	1280x800 resolution
Graphics	Intel GMA 4500MHD
Storage	320GB HDD
Optical Drive	DVD Super Multi
Operating System	Windows Vista
Battery	6-cell Li-ion
Weight	2.4 kg
Wireless	802.11a/b/g/n
