144 Chapter 3
Replacing the Speaker Module
Replacing the Keyboard
1. Align and replace the Speaker Module to the
upper case.
2. Replace the four securing screws.
3. Attach the adhesive strip on the speaker cabling to secure in place.
1. Replace keyboard cable to the mainboard, and
secure the locking latch.
2. Turn the keyboard over and place the front edge
first in the mounting.
3. Press down on the areas marked below to secure in place.
To Next Page
