Acer Aspire 8943G Series User Manual

Chapter 3 47
Disassembly Process
The disassembly process is divided into the following sections:
• External components disassembly
• Main unit disassembly
• LCD module disassembly
The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.
Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you
want to remove the mainboard, you must first remove the Keyboard, and LCD Module then disassemble the
inside assembly frame in that order.
Main Screw List
Acer Description Quantity P/N
SCREW 1.98D 3.0L K 4.6D 0.8T ZK NL 17 86.PWL02.002
SCREW 2.5D 5.7+2L K 6.0D ZK NL CR3 29 86.PWL02.003
SCREW 1.6D 2.5L K 3.0D NI NL 0.3T 6 86.PWL02.004
SCREW 2.5D 5L K 5.5D ZK NL CR3 4 86.PWL02.006
SCREW 3.0D 3.0L K 4.9D NI 2 86.PWL02.009
SCREW 2.5D 3.4+2.6L K 4.5D ZK CR3 43 86.PWL02.010

Acer Aspire 8943G Series Specifications

General

Graphics	ATI Mobility Radeon HD 5850
Storage	Up to 1TB HDD
Operating System	Windows 7 Home Premium
Weight	4.6 kg (10.14 lbs)
LAN	Gigabit Ethernet
Card Reader	5-in-1 card reader
HDMI	Yes
Processor	Intel Core i7
Display	18.4-inch, 1920x1080
RAM	Up to 8GB DDR3
Optical Drive	Blu-ray Disc / DVD-Super Multi DL drive
Audio	Dolby Home Theater v3
Wireless	Wi-Fi 802.11b/g/n
Webcam	Acer Crystal Eye webcam
Battery	8-cell Lithium Ion (Li-Ion) 4800 mAh
