Chapter 3 81
5. Remove one (1) screw from the LAN board.
6. Lift the LAN board clear of the chassis.
Removing the USB Board
1. See “Removing the Upper Cover and LCD Module” on page 66.
2. Unlock the USB board connector and disconnect the cable from the mainboard.
Step Screw Quantity Screw Type.
LAN Module
Disassembly
M2.5*6 1
