USB Failure (Right up/down side)

If the rightside USB port fails, perform the following actions one at a time to correct the problem. Do not

replace non-defective FRUs:

Other Failures

If the VGA board, LAN Port, external MIC or Speakers, PCI Express Card, 5-in-1 Card Reader or Volume

Wheel fail, perform the following general steps to correct the problem. Do not replace non-defective FRUs:

1. Check whether the drive is OK.

2. Verify that the Test Fixture is ok.

3. Swap the mainboard and retest.

Start

Check USB/B to 

M/B cable 

Re-assemble the 

USB/B cable to M/B

OK

NG

Check USB/B

OK

Swap USB/B and 

USB cable 

OK

NG

Swap M/B
