160
Chapter 6
Screw List
P
ARTNAME
ACER P/N
SCREW M2*3.0 I (BNI,NYLOK)IRON
86.SA107.001
SCREW M2.0X2.5-I(BNI)(N
YLOK) IRON
86.SA107.002
SCREW M2*5-I(BZN)(NYLOK)
86.TG607.004
SCREW M2-0.4*2-I(BNI)(NYL
OK)(7,0.6)IRON
86.W410
7.002
SCREW M2.0*3-I(NI)(N
YLOK)IRON 86.WF807.001
SCREW M3.0*3.5-I(NI)STEEL
86.SA107.003
169
171
Table of Contents
Default Chapter
2
Revision History
2
Table of Contents
7
System Specifications
11
Features
11
Audio Subsystem
12
Privacy Control
12
Dimensions and Weight
12
Power Subsystem
12
Input Devices
12
System Block Diagram
14
Your Notebook Tour
15
Front View
15
Closed Front View
16
Left View
17
Right View
17
Base View
18
Rear View
18
Indicators
19
Touchpad Basics
20
Using the Keyboard
21
Lock Keys and Embedded Numeric Keypad
21
Windows Keys
22
Hot Keys
23
Special Keys
24
Hardware Specifications and Configurations
25
System Utilities
35
BIOS Setup Utility
35
Navigating the BIOS Utility
35
Information
36
Main
37
Security
38
Removing a Password
39
Changing a Password
40
Boot
41
Exit
42
BIOS Flash Utility
43
DOS Flash Utility
44
Winflash Utility
45
Remove HDD/BIOS Password Utilities
46
Removing BIOS Passwords
47
Miscellaneous Utilities
48
Machine Disassembly and Replacement
51
Disassembly Requirements
51
Related Information
51
Replacement Requirements
51
Pre-Disassembly Instructions
52
Disassembly Process
53
External Module Disassembly Process
54
External Modules Disassembly Flowchart
54
Removing the Battery Pack
55
Removing the Dummy Card
56
Removing the Hard Disk Drive Module
57
Removing the DIMM Module
60
Removing the WLAN Module
62
Main Unit Disassembly Process
64
Main Unit Disassembly Flowchart
64
Removing the Keyboard
66
Removing the Upper Cover
68
Removing the Button Board
71
Removing the LCD Module
74
Removing the LED Board
76
Removing the Bluetooth Module
78
Removing the I/O Board
79
Removing the Mainboard
81
Removing the CRT Board
83
Removing the Thermal Module
84
Removing the RTC Battery
85
Removing the Speaker Modules
86
LCD Module Disassembly Process
88
LCD Module Disassembly Flowchart
88
Removing the LCD Bezel
89
Removing the Camera Board
92
Removing the LCD Panel
93
Removing the LCD Brackets
95
Removing the FPC Cable
96
Removing the Antennas
97
LCD Reassembly Procedure
100
Replacing the Antennas
100
Replacing the FPC Cable
103
Replacing the LCD Brackets
104
Replacing the LCD Panel
105
Replacing the Camera Board
107
Replacing the LCD Bezel
108
Main Unit Reassembly Process
111
Replacing the Speaker Modules
111
Replacing the RTC Battery
113
Replacing the Thermal Module
114
Replacing the CRT Board
115
Replacing the Main Board
116
Replacing the I/O Card
118
Replacing the Bluetooth Module
120
Replacing the LED Board
121
Replacing the LCD Module
123
Replacing the Button Board
125
Replacing the Upper Cover
128
Replacing the Keyboard
131
Replacing the Wireless LAN Module
132
Replacing the DIMM Module
134
Replacing the Hard Disk Drive
136
Replacing the Battery
138
Replace the Dummy Card
139
Troubleshooting
141
Common Problems
141
Power on Issue
142
No Display Issue
143
Random Loss of BIOS Settings
144
LCD Failure
145
Built-In Keyboard Failure
146
Touchpad Failure
147
Internal Speaker Failure
148
Internal Microphone Failure
149
HDD Not Operating Correctly
150
USB Failure (Right Up/Down Side)
151
Other Failures
151
Intermittent Problems
152
Undetermined Problems
152
POST Code Reference Tables
153
Jumper and Connector Locations
157
Mainboard Top View
157
Mainboard Bottom View
158
Clearing Password Check and BIOS Recovery
159
Mainboard CMOS Discharge
159
BIOS Recovery by Crisis Disk
160
FRU (Field Replaceable Unit) List
161
Exploded Diagrams
161
Main Assembly
162
LCD Assembly
163
FRU List
164
Screw List
170
Model Definition and Configuration
171
Aspire 1810T/1410
171
Aspire One 752
229
Test Compatible Components
241
Aspire 1810T/1410
242
Aspire One 752
246
Online Support Information
251
Index
253
