34 Chapter 2
DOS Flash Utility
Perform the following steps to use the DOS Flash Utility:
1. Press F2 during boot to enter the Setup Menu.
2. Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move
USB HDD to position 1.
3. Execute the FLASH.BAT batch file to update BIOS. Or enter C:\ Flash it bios ver.fd/dc
The flash process begins as shown.
4. In flash BIOS, the message Please do not remove AC Power Source displays.
NOTE: If the AC power is not connected, the following message displays.
Plug in the AC power to continue.
5. Flash is complete when the message Flash programming complete displays.
Item S pecificHelp
Use < > or < > to select
a device, then press
<F5> to move it down the
list, or <F6> to move
it up the list. Press
<Esc> to escape the menu
F1
ESC
Help
Exit
Select Item
Select Menu
Change Values
Select SubMenu
Enter
F9
F10
Setup Default
Save and Exit
Boot priority order:
1. IDE0 : Hitachi HTS545032B9A300
2. IDE1 :
3. Network Boot : Atheros Boot Agent
4. USB HDD
5. USB CDROM :
6. USB FDD :
Boot priority order:
1. IDE0 : Hitachi HTS545032B9A300
2. IDE1 :
3. Network Boot : Atheros Boot Agent
4. USB HDD
5. USB CDROM :
6. USB FDD :
F5/F6
InsydeH20 Setup Utility
Information
Main Boot
Exit
Security
