Acer ASPIRE ONE 1410 User Manual

58 Chapter 3
Removing the Upper Cover
1. See “Removing the Keyboard” on page 56.
2. Disconnect the button board FCC from the main board by unlocking the FCC cable and pulling away.
3. Remove the nine screws in the upper cover.
Screw List
Step Size Quantity Screw Type
Upper Cover
Disassembly
M2*3 3 (green call out)
M2*5 6 (red call out)
