To set the duty cycle
Applies only to square waves. At power-on, the duty cycle for square waves
is 50%. You can adjust the duty cycle for a square waveform from 20%
to 80%, in increments of 1% (for frequencies above 5 MHz, the range is 40%
to 60%). The following steps show you how to change the duty cycle to 45%.
1 Select the square wave function.
Notice that the annunciator turns on, indicating that the square
wave function is enabled.
Shift % Duty 2 Enable the duty cycle modify mode.
The displayed duty cycle is either the power-on value or the previous
value selected.
50 % DUTY
This message appears on the display for approximately 10 seconds.
Repeat this step as needed.
Enter Number
3 Enter the desired duty cycle.
1
4 5 Notice that the Num annunciator turns on and “ENTER NUM” flashes on
the display, indicating that the number mode is enabled.
45
To cancel the number mode, press
Shift Cancel .
Enter 4 Output the waveform with the displayed duty cycle.
45 % DUTY
1
You can also use the knob and arrow keys to enter a number.
Chapter 2 Quick Start
To set the duty cycle
28
