To rack mount the function generator
You can mount the function generator in a standard 19-inch rack
cabinet using one of three optional kits available. Instructions and
mounting hardware are included with each rack-mounting kit.
Any Agilent System II instrument of the same size can be rack-mounted
beside the 33120A Function Generator.
Remove the carrying handle, and the front and rear rubber bumpers,
before rack-mounting the function generator.
To remove the handle, rotate it to the vertical position and pull the ends outward.
Front Rear (bottom view)
To remove the rubber bumper, stretch a corner and then slide it off.
2
Chapter 2 Quick Start
To rack mount the function generator
33
