To output a dc voltage
In addition to generating waveforms, you can also output a dc voltage in
the range
5 Vdc (into a 50W termination). The following steps show you
how to output +155 mVdc.
1 Press the key and hold it down for more than 2 seconds.
To enter the dc voltage mode, press the
Offset key or any key in the top row
of function keys and
hold it down for more than 2 seconds. The displayed
voltage is either the power-on value or the previous offset voltage selected.
DCV
+0.000 VDC
Enter Number
2 Enter the magnitude of the desired voltage.
1
1 5 5 Notice that the Num annunciator turns on and “ENTER NUM” flashes on
the display, indicating that the number mode is enabled.
155
To cancel the number mode, press
Shift Cancel .
Shift 3 Set the units to the desired value.
¿
kHz
m Vrms
At this point, the function generator outputs the displayed dc voltage.
Notice that the
Offset annunciator turns on (all other annunciators are
off), indicating that a dc voltage is being output. The annunciator will
turn on when the offset is any value other than 0 volts.
+155.0 mVDC
1
You can also use the knob and arrow keys to enter a number.
Offset
Chapter 2 Quick Start
To output a dc voltage
30
