General| Type | Digital Oscilloscope |
|---|---|
| Bandwidth | 100 MHz |
| Sample Rate | 200 MSa/s |
| Memory Depth | 2 Mpts |
| Vertical Resolution | 8 bits |
| Input Coupling | AC, DC, GND |
| Timebase Range | 5 ns/div to 50 s/div |
| Input Impedance | 1 MΩ |
| Maximum Input Voltage | 400 V (DC + peak AC) |
| Trigger Modes | Edge, Pulse Width, Pattern |
| Interface | GPIB, RS-232 |
| Power Requirements | 100-240 V AC, 50/60 Hz |
