Overview 1
N9310A User’s Guide 5
•
FM configures a frequency modulation.
•
FM configures a phase modulation.
•
Pulse configures a pulse modulation.
•
I/Q actives an I/Q modulation.
•
Sweep configures RF/LF/Amplitude sweep.
•
Trigger triggers an armed sweep.
•
Utility sets the system configurations
•
Local returns the signal generator from remote to local.
•
File saves, recalls or deletes customized configuration files.
•
LF Out configures a low frequency signal.
7Mod On/OffPressing hardkey toggles the modulator
state between On and Off. A MOD On/Off annunciator is
visible on the screen, indicating whether the modulator is
enabled or not.
You also have to activate each individual modulation (for
example, > AM On), otherwise no modulation is applied
to the output carrier signal, even though the modulator is
enabled (MOD On).
8KnobThe knob increases or decreases a value or a numeric
digit, or moves to select an item up and down in a list.
9 Arrow keys The left and right arrow keys shift the selected
digit in the active entry area of the display; Once an
individual digit is selected, you can change its value by
rotating the knob.
10 RF On/Off The hardkey toggles the RF output state
between On and Off. A RF On/Off annunciator is always
visible on the display, indicating whether the RF output is
enabled or not.
11 RF Out connector This female N- type connector provides the
output for RF signals. The impedance is 50 ohm. The damage
level is +36 dBm maximum.
Mod
On/Off
AM
RF
On/Off
