3. To install a M.2 2230 solid-state drive in SSD slot one, see installing the M.2 2230 solid-state drive in SSD slot one.
4. To install a M.2 2280 solid-state drive in SSD slot one, see
installing the M.2 2280 solid-state drive in SSD slot one.
Removing the M.2 2230 solid-state drive in slot two
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: This procedure is applicable only to computers shipped with an M.2 2230 solid-state drive installed in M.2 slot two
(SSD2).
NOTE: The M.2 card installed on M.2 slot two (SSD2) will depend on the configuration ordered. Supported card configurations:
● M.2 2230 solid-state drive
● M.2 2280 solid-state drive
The following image(s) indicate the location of the M.2 2230 solid-state drive in slot two and provides a visual representation of the
removal procedure.
22
