4. Install the M.2 2230 solid-state drive or M.2 2280 solid-state drive in slot one, whichever applicable.
5. Install the M.2 2230 solid-state drive or M.2 2280 solid-state drive in slot two, whichever applicable.
6. Install the memory module.
7. Install the base cover.
8. Follow the procedure in
After working inside your computer.
Fan and heat-sink assembly
Removing the fan and heat-sink assembly
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the memory module.
4. Remove the M.2 2230 solid-state drive or M.2 2280 solid-state drive in slot one, whichever applicable.
5. Remove the M.2 2230 solid state drive or M.2 2280 solid-state drive in slot two, whichever applicable.
6. Remove the
wireless card.
7. Remove the rear-I/O cover.
8. Follow the procedure from step 1 to step 20 in Removing the system board.
NOTE: The system board can be removed and installed along with the ethernet and audio board, USB board, and fan and
heat sink-assembly. This simplifies the removal and installation procedure and avoids breaking the thermal bond between the
system board and heat sink.
About this task
CAUTION: The heat sink may become hot during normal operation. Allow sufficient time for the heat sink to cool before
you touch it.
NOTE: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils in your skin can
reduce the heat transfer capability of the thermal grease.
The following image(s) indicate the location of the fan and heat-sink assembly and provides a visual representation of the removal
procedure.
57
