5. Connecting control apps
The CQ-MixPad app provides full remote control of the CQ over a network
connection from an iOS, Android, macOS or Windows device.
CQ4You is an easy-to-use personal monitoring app, which also works over a
network, and controls the send levels to one of the outputs.
Up to 2 instances of CQ-MixPad can be connected to a CQ at once, along with up to
6 instances of CQ4You (one for every output).
Note that only control messaging is shared over the network connection between
the CQ and any connected app, no audio is transmitted or received. To send audio
wirelessly from a device to the CQ, the Bluetooth connection can be used.
 Remote control of the CQ is not possible via Bluetooth.
The firmware on the CQ and all app versions must have the same major release
number. This is the first two digits of each release number.
Firmware V1.1.3 and App V1.1.5 = compatible
Firmware V1.1.3 and App V1.2.3 = not compatible
First connection to a CQ-20B
1) After booting, the Chromatic Meter (CM) LED will flash to show the enabled
network, if not, carry out a network or full reset of the unit.
2) Press the reset button to toggle between the two options.
• flashing BLUE
⚫
= Wi-Fi enabled with default settings
• flashing YELLOW
⚫
= Ethernet enabled with default settings
 The Chromatic Meter (CM) LED will continue to flash until a network has been set up
and secured.
3) Connect the device running CQ-MixPad to either the built-in Wi-Fi, to the
same network as the CQ is connected to, or connect directly to the CQ
using a network cable.
4) Complete the setup of the network as described in the rest of this section.

ALLEN & HEATH CQ-20B Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	24 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Nominal input level	17 dBu
Output impedance	75 Ω
Total Harmonic Distortion (THD)	0.002 %
Built-in display	-
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Bluetooth version	4.1
XLR out	8
RJ-45 ports quantity	1
USB 2.0 ports quantity	2
Number of microphone inputs	20
Rack capacity	19U
USB connector type	USB Type-A, USB Type-B
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	- W

Weight and Dimensions

Depth	154 mm
Width	372 mm
Height	134 mm
Weight	2600 g
Package type	Box
Package depth	260 mm
Package width	450 mm
Package height	250 mm
Package weight	3300 g
