ALLEN & HEATH XB-14 User Manual

Allen & Heath 11 XB-14 User Guide
Frequency Response
Mic in to PGM L/R Out, 30dB gain +0.5/-1dB 20Hz to 20kHz.
Line in to PGM L/R out 0dB gain +0.5/-1dB 10Hz to 30kHz
Stereo in to PGM L/R out +0.5/-1dB 10Hz to 30kHz
Headroom
Analogue Headroom from nominal (0Vu) Outputs 21dB
USB in & out headroom from nominal (0Vu) 14dB
Analogue Headroom from nominal (0Vu) Mix point 24dB
SPECIFICATIONS (continued)
Crosstalk & Attenuation (dB 22-22kHz)
Mono fader attenuation (dB relative to +10dBu) 1kHz/10kHz -100/-90
Mono ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -100/-90
TELCO fader attenuation (dB relative to +10dBu) 1kHz/10kHz -99/-92
TELCO ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -100/-100
Stereo fader attenuation (dB relative to +10dBu) 1kHz/10kHz -99/-86
Stereo ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -100/-93
PGM fader attenuation (dB relative to +10dBu) 1kHz/10kHz -102/-99
TELCO clean-feed isolation from I/P (dB relative to +10dBu) 1kHz/10kHz -57/-40
Stereo separation, L in to PGM R out. dBr 1kHz/10kHz -77/-56

ALLEN & HEATH XB-14 Specifications

Operating Levels

Mono channel Mic input range	+6 to –63dBu
Mono channel Line input range	+10 to –26dBu
Insert point nominal level	0dBu
Stereo input nominal level	0dBu
Telco channel input range	+10 to –26dBu
External monitor inputs nominal level	0dBu

Output Levels

PGM L & R outputs nominal level	+4dBu
PGM Mono output nominal level	0dBu
PGM L & R inserts nominal level	-2dBu
Aux output nominal level	0dBu
Mix B outputs nominal level	0dBu
Rec outputs nominal level	0dBu

Audio Performance

THD+n Mic in to PGM L/R Out	0.003%
THD+n Mic in to PGM Out	0.007%
THD+n Line in to PGM L/R out	0.004%
THD+n Stereo in to PGM out	0.003%
Noise Mic Pre EIN	-127dBu
Noise PGM out	-92dBu

Frequency Response

Mic in to PGM L/R Out	20Hz to 20kHz
Line in to PGM L/R out	10Hz to 30kHz
Stereo in to PGM L/R out	10Hz to 30kHz

Headroom

Analogue Headroom Outputs	21dB
USB in & out headroom	14dB
Analogue Headroom Mix point	24dB

Crosstalk & Attenuation

Mono fader attenuation 1kHz/10kHz	-99/-90
Mono ON switch attenuation 1kHz/10kHz	-96/-80
TELCO fader attenuation 1kHz/10kHz	-99/-92
TELCO ON switch attenuation 1kHz/10kHz	-102/-100
Stereo fader attenuation 1kHz/10kHz	-100/-91
Stereo ON switch attenuation 1kHz/10kHz	-102/-102
