ALLEN & HEATH XB-14 User Manual

Allen & Heath 35 XB-14 User Guide
WIRING NOTES
GROUND
RETURN
SEND
RETURN
OUT
IN
SEND
INSERT
PROCESSOR
LINK RING TO SLEEVE TO UNBALANCE
T
R
S
T
R
S
T
R
S
Insert cable wiring
1=ground
2=hot (+)
3=cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2=hot (+)
1=ground
3=cold (-)
RCA PHONO CABLE
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
1=ground
2=hot (+)
3=cold (-)
2=hot (+)
1=ground
3=cold (-)
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
BALANCED
BALANCED
XLR FEMALE
XLR MALE
BALANCED
UNBALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
UNBALANCED
adapter
UNBALANCED
INSTRUMENT CABLE
TRS JACK CABLE
MIC CABLE
TRS to XLR-F CABLE
TRS to XLR-M CABLE
TO
FROM
INPUT
OUTPUT
2 Outputs to 1 Input
Y-Adapter
No !
1 Output to 2 Inputs
Y-Adapter
Yes
General
Wiring
Information

ALLEN & HEATH XB-14 Specifications

Operating Levels

Mono channel Mic input range	+6 to –63dBu
Mono channel Line input range	+10 to –26dBu
Insert point nominal level	0dBu
Stereo input nominal level	0dBu
Telco channel input range	+10 to –26dBu
External monitor inputs nominal level	0dBu

Output Levels

PGM L & R outputs nominal level	+4dBu
PGM Mono output nominal level	0dBu
PGM L & R inserts nominal level	-2dBu
Aux output nominal level	0dBu
Mix B outputs nominal level	0dBu
Rec outputs nominal level	0dBu

Audio Performance

THD+n Mic in to PGM L/R Out	0.003%
THD+n Mic in to PGM Out	0.007%
THD+n Line in to PGM L/R out	0.004%
THD+n Stereo in to PGM out	0.003%
Noise Mic Pre EIN	-127dBu
Noise PGM out	-92dBu

Frequency Response

Mic in to PGM L/R Out	20Hz to 20kHz
Line in to PGM L/R out	10Hz to 30kHz
Stereo in to PGM L/R out	10Hz to 30kHz

Headroom

Analogue Headroom Outputs	21dB
USB in & out headroom	14dB
Analogue Headroom Mix point	24dB

Crosstalk & Attenuation

Mono fader attenuation 1kHz/10kHz	-99/-90
Mono ON switch attenuation 1kHz/10kHz	-96/-80
TELCO fader attenuation 1kHz/10kHz	-99/-92
TELCO ON switch attenuation 1kHz/10kHz	-102/-100
Stereo fader attenuation 1kHz/10kHz	-100/-91
Stereo ON switch attenuation 1kHz/10kHz	-102/-102
