Allen & Heath 26 XB-14 User Guide
REMOTE INTERFACE CONNECTORS
Start/Cue logic
The Start/Cue logic from the Stereo channel ON switches is designed to interface to a common standard employed
by Denon and Pioneer equipment. The logic signals are usually wired to a 2 pole 3.5mm jack plug where a low pulse
on the tip starts the deck and a low pulse on the sleeve stops or cues the deck. There needs to be some form of
ground connection between the equipment for this to work—normally effected by the audio connector leads.
Notice that there are Start/Cue outputs for 7 machines even though there are only 4 Stereo channel ON switches.
That’s because there are dual inputs on 3 of the stereo channels making a total of 7 sources and the XB-14 only sends
a Start/Cue signal to the deck selected as a source to the channel whose switch is pressed. It’s clever like that!
15 Way D socket connector REMOTE A
PIN FUNCTION
1 M1 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
2 M3 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
3 T1 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
4 M1 EXTERNAL MUTE (INPUT, ACTIVE LOW)
5 M3 EXTERNAL MUTE (INPUT, ACTIVE LOW)
6 T1 EXTERNAL MUTE (INPUT, ACTIVE LOW)
7 CUT CRM SPEAKERS (INPUT, ACTIVE LOW)
8 GROUND
9 M2 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
10 M4 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
11 T2 FADER UP LOGIC (OPEN COLLECTOR OUTPUT)
12 M2 EXTERNAL MUTE (INPUT, ACTIVE LOW)
13 M4 EXTERNAL MUTE (INPUT, ACTIVE LOW)
14 T2 EXTERNAL MUTE (INPUT, ACTIVE LOW)
15 N/C
15 Way D plug connector REMOTE B
PIN FUNCTION
1 ST1 START PULSE (OPEN COLLECTOR OUTPUT)
2 ST2 START PULSE (OPEN COLLECTOR OUTPUT)
3 ST3 START PULSE (OPEN COLLECTOR OUTPUT)
4 ST4 START PULSE (OPEN COLLECTOR OUTPUT)
5 ST5 START PULSE (OPEN COLLECTOR OUTPUT)
6 ST6 START PULSE (OPEN COLLECTOR OUTPUT)
7 ST7 START PULSE (OPEN COLLECTOR OUTPUT)
8 GROUND
9 ST1 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
10 ST2 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
11 ST3 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
12 ST4 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
13 ST5 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
14 ST6 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
15 ST7 STOP/CUE PULSE (OPEN COLLECTOR OUTPUT)
