Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 107
Configure the Module in a GuardLogix Controller System Chapter 5
Values and States of Tags
This table shows the values and states of the tags.
Data Description
Digital Input Data
Run Mode
STANDARD
Indicates whether consumed data is actively being updated by a device that is in one of these states:
Run mode: 1 Idle State: 0
Connection Faulted
STANDARD
Indicates the validity of the safety connection between the safety producer and the safety consumer.
Valid: 0 Faulted: 1
Safety Input Data
SAFETY
Indicates the ON/OFF state of each input circuit.
ON: 1 OFF: 0
Combined Safety Input Status
SAFETY
An AND of the status of all input circuits.
All circuits are normal: 1
An error was detected in one or more input circuits: 0
Individual Safety Input Status
SAFETY
Indicates the status of each input circuit.
Normal: 1 Fault (Alarm): 0
Combined Safety Output Status
SAFETY
An AND of the status of all safety output circuits.
All circuits are normal: 1
An error has been detected in one or more output circuits: 0
Individual Safety Output Status
SAFETY
Indicates the status of each safety output circuit.
Normal: 1 Fault (Alarm): 0
Muting Lamp Status
SAFETY
Indicates the status when circuits T1 and T3 are configured as the muting lamp output.
Normal: 1 Fault (Alarm): 0
Output Readback
STANDARD
Monitors the presence of 24V on the output circuit. Readback is ON (1) if 24V is on output terminal.
ON: 1 OFF: 0
Individual Test Output Status
STANDARD
Indicates the status of each of the test output circuits.
Normal: 1 Fault (Alarm): 0
Input Power Error Bit
STANDARD
Indicates field power that is supplied is within specification.
Power error: 1 Power OK: 0
Output Power Error Bit
STANDARD
Indicates field power that is supplied is within specification.
Power error: 1 Power OK: 0
Digital Output Data
Safety Output Data
SAFETY
Controls the safety output.
ON: 1 OFF: 0
Standard Output Data
STANDARD
Controls the test output when Test Output mode is set to a standard output.
ON: 1 OFF: 0
