Allen-Bradley Ultra3000 User Manual

Publication 2098-IN003E-EN-P — April 2004
Specifications and Dimensions A-11
AC Line Filter Specifications
The following AC line filters are compatible with the Ultra3000 drives.
Use the table below to determine which AC line filter is best suited for
your Ultra3000 drive (based on the length of the motor cables).
AC Line Filter
Catalog Number
Specifications
Voltage Phase Current
Power
Loss
Weight
kg (lb)
Humidity Vibration
Operating
Temperature
2090-UXLF-106
250V ac
50/60 Hz
Single
6A @ 50° C
(122° F)
3.5W
0.3
(0.66)
90% RH
10-200 Hz
@ 1.8 g
-25 to 85° C
(-13 to 185 ° F)
2090-UXLF-110
10A @ 50° C
(122° F)
2.7W
0.95
(2.0)
2090-UXLF-123
23A @ 50° C
(122° F)
10W
1.6
(3.5)
2090-UXLF-132
32A @ 50° C
(122° F)
20W
2090-UXLF-136
36A @ 50° C
(122° F)
–
1.75
(3.9)
2090-UXLF-336
250V ac
50/60 Hz
Three
–
2.7
(5.9)
2090-UXLF-350
50A @ 50° C
(122° F)
–
2090-UXLF-HV323
520V ac
50/60 Hz
23A @ 50° C
(122° F)
20W
1.6
(3.5)
2090-UXLF-HV330
30A @ 50° C
(122° F)
51W
1.8
(4.0)
2090-UXLF-HV350
50A @ 50° C
(122° F)
25W
4.8
(10.6)
Ultra3000 Drives
AC Line Filter Catalog Number
Motor Cables < 30 m Motor Cables > 30 m
2098-DSD-005x-xx 2090-UXLF-106 2090-UXLF-110
2098-DSD-010x-xx 2090-UXLF-110 2090-UXLF-110
2098-DSD-020x-xx 2090-UXLF-123 2090-UXLF-123
2098-DSD-030x-xx 2090-UXLF-136 2090-UXLF-132
2098-DSD-075x-xx 2090-UXLF-336 2090-UXLF-HV330
2098-DSD-150x-xx 2090-UXLF-350 2090-UXLF-HV350
2098-DSD-HV030x-xx
2098-DSD-HV050x-xx
2098-DSD-HV100x-xx
2098-DSD-HV150x-xx
2090-UXLF-HV323 2090-UXLF-HV323
2098-DSD-HV220x-xx 2090-UXLF-HV330 2090-UXLF-HV330
