WIRING DIAGRAM KEY - RSV 1000 R - RSV 1000 R FACTORY
1) Multiple connectors
2) Fall sensor
3) Highbeam relay
4) Low beam relay
5) Horn
6) Clutch control lever switch
7) Lights/LAP diode
8) Left dimmer switch
9) Dashboard
10) Right dimmer switch
11) Key-operated switch
12) Front stoplight switch
13) Rear stoplight switch
14) Rear right direction indicator
15) Taillight
16) Rear left direction indicator
17) Auxiliary fuses (15A)
18) Speed sensor
19) Flywheel
20) Voltage regulator
21) Starter motor
22) Starter relay
23) Main fuses (30A) (ignition)
24) Battery
25) Injection relay
26) Oil pressure sensor
27) Purge valve (California only)
28) Neutral light switch
29) Cooling fan relay
30) Fan relay
31) Lambda sensor
32) -
33) Side stand switch
34) Intake flap
35) Fuel sensor
36) Fuel pump
37) Air thermistor
38) Coolant thermistor
39) Automatic choke
40) Intake pressure sensor
41) Atmospheric pressure sensor
42) Throttle sensor
43) Twin coil
44) Front cylinder spark plug
45) Rear cylinder spark plug
46) Front cylinder injector
47) Rear cylinder injector
48) Camshaft sensor
49) Pick-up
50) Engine Control Unit (ECU)
51) Front left direction indicator
52) Left headlight
53) Right headlight
54) Parking light
55) Left low beam bulb
56) Left highbeam bulb
57) Right highbeam bulb
58) Right low beam bulb
59) Right beam parking light
60) Front right direction indicator
61) TEST connectors
62) License plate light
63) Immobilizer control unit (where
immobilizer system is fitted)
64) Immobilizer antenna (where
immobilizer system is fitted)
65) Pick-up cables shielding
66) Mapping change jumper
X) Dashboard connector (20-way)
Y) Electronic unit connector (26-way)
Z) Electronic unit connector (16-way)
CABLE COLORS
Ar Orange M Brown
Az Light blue N Black
B Blue R Red
Bi White V Green
G Yellow Vi Violet
Gr Grey Ro Pink
