APRILIA RSV 1000 R FACTORY User Manual

29
use and maintenance RSV 1000 R - RSV 1000 RFACT
USA USA
KEY
1) Rear shock absorber
2) Passenger right footrest
(snaps closed/open)
3) Taillight
4) Glove/tool kit compartment
5) Passenger saddle
(glove/tool kit compartment
cover)
6) Passenger grab strap
7) Engine Control Unit
8) Right side panel
9) Fuel tank
10)Coolant expansion tank
cap
11)Fuel tank filler cap
12)Air cleaner
13)Right rearview mirror
14)Front brake fluid reservoir
15)Secondary fuse carrier (15A)
16)Right side fairing
17)Horn
18)Lower fairing
19)Expansion tank
20)Rear brake fluid reservoir
21)Rear brake master cylinder
22)Rear brake lever
23)Rider right footrest
22 1823
1
3
2
192021
15
16
17
1398654 11 12107
14
APRum_RSV1000R##06_####.book Page 29 Monday, February 6, 2006 2:48 PM

APRILIA RSV 1000 R FACTORY Specifications

General

Engine Type	V-Twin, 4-stroke
Displacement	998 cc
Transmission	6-speed
Max Power	143 hp (107 kW) @ 10, 000 rpm
Max Torque	107 Nm at 7500 rpm
Front Suspension	Öhlins upside-down fork
Rear Suspension	Öhlins monoshock
Front Brakes	Dual 320 mm discs
Rear Brakes	Single 220 mm disc
Dry Weight	185 kg
Fuel Capacity	18 liters
Frame	Aluminum twin spar
