SBS COSMOS
REFRIGERATOR 10.01.2014 / REV NO: 03
37
10. ELECTRONIC AND CONTROL SYSTEM
Sensors (Frz Eva, Frz Air, FF Eva, FF Air, Icematic)
Door reed switch (FRZ, FF)
Blue led board (optional)
Water valve group (inlet, water, ice)
Water dispenser key (microswitch)
Compressor: Coolant gas circulation is enabled by the compressor. Electric supply is made
via a protective thermal. The auxiliary coil which is activated for a short time during first
startup of the compressor is deactivated by PTC.
Freezer fan motor (Freezer Compartment Fan Motor): It is mounted on the inner body of
refrigerator behind the rear cover of evaporator. It ensures circulation of the freezer
compartment air in the freezer compartment by passing it continuously over the evaporator.
Condenser fan motor: It is located at the bottom of the cabin. It prevents excessive heating
of the condenser and drops condensation pressure to increase the efficiency of the fridge. It
runs when the compressor starts and stops when it stops.
