SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
34
Sensitivity: Public
10. ELECTRONIC AND CONTROL SYSTEM
Component
1
Compressor
2
Defrost heater
3
Freezer fan
4
Condenser fan
5
Sensors (Frz Eva, Frz Air, FF Eva, FF Air, Icematic)
6
Fresh Food Fan
7
Flange Heater
8
Thermal fuse
9
PTC relay
10
Thermic
11
Door reed switch (FRZ, FF)
12
DC Illumination card
13
Ionizer
14
Blue led board (optional)
15
Water valve group (inlet, water, ice)
16
Icematic motor
17
Ice selector motor
18
Ice lid motor
19
Ice lid heater
20
Water dispenser key (microswitch)
21
Ice pipe heater
22
Water dispenser heater
23
Ice crusher motor
24
Supply line filter
25
Capacitor
26
Electronic control board
27
Indicator board
28
Reed switch
Compressor: Coolant gas circulation is enabled by the compressor. Electric supply is made
via a protective thermal. The auxiliary coil which is activated for a short time during first
startup of the compressor is deactivated by PTC.
Freezer fan motor (Freezer Compartment Fan Motor): It is mounted on the inner body of
refrigerator behind the rear cover of evaporator. It ensures circulation of the freezer
compartment air in the freezer compartment by passing it continuously over the evaporator.
