arcelik BEKO G91633NE User Manual

SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
77
Sensitivity: Public
12.26. Water pipe (8mm)
Used service number: 1182
1 2
 8 mm water pipe coming from the water valve is attached to the 6.35mm pipe by means
of quick fit.
 There are 2 quick fits at the lower part of the cabin (cabin bottom). 6.35mm pipe
connected with 8mm pipe is connected to the water dispenser. 6.35mm pipe coming
from the valve and connected to the blue pipe with quick fit goes to icematic inlet.
12.27. Rear cover group
Used service number: 831
1
6.35mm pipe
0.31in pipe
