Asus P9D-E/4L User Manual

xii
Processor Support / System Bus
1 x Socket LGA1150
Intel
®
Xeon
®
Processor E3-1200 v3 Product
Family
Intel
®
Core™ i3 Processor Family*
Core Logic
Intel
®
C224 Chipset
Form Factor
ATX, 12 in. x 9.6 in.
ASUS Features
Fan Speed Control
Rack Ready
(Rack and Pedestal
dual use)
ASWM Enterprise
Memory
Total Slots
4 (2 Channels)
Capacity
Maximum up to 32GB
Memory Type
DDR3 1333/1600 ECC UDIMM
Expansion
Slots
(follow SSI
Location
number)
Total PCI/PCI-E Slots
7
Slot Location 1
1 x PCI 32bit/33 MHz
Slot Location 2
1 x PCI 32bit/33 MHz
Slot Location 3
1 x PCI-E x1 (x1 Gen2 link)
Slot Location 4
1 x PCI-E x8 (x8 Gen3 link)
Slot Location 5
1 x PCI-E x8 (x8 Gen3 link)
Slot Location 6
1 x PCI-E x16 (x16 Gen3 link)
(Auto switch to x8 link if slot 5 is occupied)
Slot Location 7
1 x PCI-E x1 (x1 Gen2 link); MIO supported
Additional Slot 1
1 x PIKE Slot for Storage expansion
(Gen3 supported)
Storage
SATA Controller
Intel
®
C224:
- 2 x SATA 3Gb/s ports
- 4 x SATA 6Gb/s ports
- Intel
®
Rapid Storage Technology Enterprise
(RSTe) supports software RAID 0, 1, 10, & 5
(Windows)
SAS Controller
Optional:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G HW RAID card
ASUS PIKE 2208 8-port SAS 6G HW RAID card
ASUS PIKE 2308 8-port SAS 6G RAID card
ASUS PIKE 9230 4-port SATA 6G RAID card
P9D-E/4L Specications Summary
(continued on the next page)
* Refer to www.asus.com for the complete list of supported CPUs.

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
