ASUS P9D-E/4L
4-25
4.4.12 Onboard LAN Conguration
This allows you to change the enable or disable the onboard LAN.
INTEL I210 LAN1 - LAN4 Enable [Enabled]
Allows you to enable or disable the INTEL I210 LAN function in the system.
Configuration Options: [Enabled] [Disabled]
INTEL I210 LAN1/LAN2 OpROM [PXE], INTEL I210 LAN3/LAN4 OpROM
[Disabled]
Allows you to launch the Intel I210 LAN OpROM. Configuration options: [Disabled] [PXE]
[iSCSI]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
INTEL I210 LAN
Disable/Enable
INTEL I210 LAN1 Enable [Enabled]
INTEL I210 LAN1 OpROM [PXE]
INTEL I210 LAN2 Enable [Enabled]
INTEL I210 LAN2 OpROM [PXE]
INTEL I210 LAN3 Enable [Enabled]
INTEL I210 LAN3 OpROM [Disabled]
INTEL I210 LAN4 Enable [Enabled]
INTEL I210 LAN4 OpROM [Disabled]
Onboard LAN Conguration
INTEL I210 LAN1 MAC: 00:E0:18:10:18:E8
INTEL I210 LAN2 MAC: 00:E0:18:10:18:E9
INTEL I210 LAN3 MAC: 00:E0:18:10:18:EA
INTEL I210 LAN4 MAC: 00:E0:18:10:18:EB
4.4.13 MIO Card Conguration
This item allows you to set MIO Card configuration settings.
Front Panel Type [AC97]
Allows you to select the front Panel type of the MIO. Configuration options:
[AC97] [HD]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
MIO Card Type
Set MIO Card
MIO Card Type [ALC 892]
Front Panel Type [AC97]

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
