Asus P9D-E/4L User Manual

ASUS P9D-E/4L 6-3
6.1 RAID driver installation
After creating the RAID sets for your server system, you are now ready to install an
operating system to the independent hard disk drive or bootable array. This part provides the
instructions on how to install the RAID controller drivers during OS installation.
6.1.1 Creating a RAID driver disk
The system does not include a floppy drive. You have to use a USB floppy drive when
creating a SATA RAID driver disk.
A floppy disk with the RAID driver is required when installing Windows
®
or Red Hat
®
Enterprise operating system on a hard disk drive that is included in a RAID set. You can
create a RAID driver disk in DOS (using the Makedisk application in the support DVD).
To create a RAID driver disk in DOS environment:
1. Place the motherboard support DVD in the optical drive.
2. Restart your computer.
3. Enter the BIOS Setup.
4. Select the optical drive as the first boot priority to boot from the support DVD. Save
your changes.
5. Exit the BIOS Setup and restart your computer.
The following Makedisk menu appears.
6. Select the
C22x INTEL RAID Driver
and press <Enter> to go to the sub-menu.
Create Driver Diskette Menu
C22x INTEL RAID Driver
Write DMI
FreeDOS command prompt
7. From the C22x Intel RAID Driver sub-menu, use the Up or Down arrow keys to select the
driver and press <Enter> to create the RAID driver disk.
C22x INTEL RAID Driver
Windows 32 bit(AHCI / AHCI RAID)
Windows Server 2012 64 bit (AHCI / AHCI RAID)
Back
Exit

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
