4.4.16 APM
Allows you to configure the Advance Power Management (APM) settings.
Restore AC Power Loss [Last State]
Allows you to set the state the system will go to after an AC power loss.
Configuration options: [Power Off] [Power On] [Last State]
Power On By PCI [Disabled]
You can use this option to enable or disable the Wake-on-LAN feature of the Intel
®
LAN. Configuration options: [Disabled] [Enabled]
Power On By PCIE [Disabled]
This allows you to enable or diasble the PCIE devices to generate a wake event.
Configuration options: [Disabled] [Enabled]
Power On By RTC [Disabled]
This item allows you to enable or disable RTC to generate a wake event. When
set to [Enabled], the items
RTC Alarm Date (Days)
and
Hour/Minute/Second
becomes user-configurable where you can set values.
EUP Ready [Disabled]
This item allows you to switch off some power at S5 to get the system ready for
EuP requirement. Configuration options: [Enabled] [Disabled]
4.4.15 Runtime Error Logging Support
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Runtime Error Logging Support [Disabled]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Restore AC Power Loss [Last State]
Power On By PCI [Disabled]
Power On By PCIE [Disabled]
Power On By RTC [Disabled]
EuP Ready [Disabled]
Specify what state
to go to when power
is re-applied after
a power failure (G3
state).
Runtime Error Logging Support [Disabled]
Allows you to enable or disable the Runtime Error Logging Support. Configuration
options: [Disabled] [Enabled]
Enable/Disable
Runtime Error Logging
Support.

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
