Asus P9D-E/4L User Manual

6-20 Chapter 6: Driver installation
6.5 Installing the VGA driver
This section provides the instructions on how to install the ASPEED Video Graphics
Adapter (VGA)
driver.
To install the ASPEED VGA driver on Windows
®
Server 2008 R2:
1. Restart the computer.
2. Log in with Administrator
privileges.
3. Insert the Motherboard Support DVD to the optical drive.
The support DVD automatically displays the
Drivers menu if Autorun is enabled in your
computer.
4. From the
Main Menu
, click
ASPEED
AST2300/AST1300 Display Driver
on
the
Drivers
tab to start the installation.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the support DVD.
5. From the
License Agreement
window,
select
I accept the terms
and click
Nex
t..

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
