ASUS P9D-E/4L
1-3
1.1 Welcome!
Thank you for buying an ASUS
®
P9D-E/4L motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard and hardware devices on it, check the
items in your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
If any of the above items is damaged or missing, contact your retailer.
Items Standard Gift Box Pack Standard Bulk Pack
I/O Shield
1
1
Cables
SATA DOM Power cable
1 --
SATA 3G cable
2 --
SATA 6G cable
4 --
COM port cable
1 --
Application CD
Support CD
1 1
ASWM Enterprise SDVD
1 1
Documentation Motherboard User Guide
1 1
Accessory
Metal Plate for LGA1150
1 1
Packaging Qty.
1 pc per carton 10 pcs per carton
Optional items Description
PIKE 2008 LSI 8-port SAS 6G RAID card
PIKE 2008/IMR LSI 8-port SAS 6G RAID card
PIKE 2108 LSI 8-port SAS 6G HW RAID card
PIKE 2208 LSI 8-port SAS 6G HW RAID card
PIKE 2308 LSI 8-port SAS 6G RAID card
PIKE 9230 MARVELL 4-port SATA 6G RAID card
ASMB7-iKVM Remote Management solution provides KVM over IP solution
MIO-892
Discrete 8-channel audio card provides clearest high quality
sounds

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
