ASUS P9D-E/4L
4-19
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Change PCI Express
Devices Settings.
PCI Bus Driver Version V 2.05.02
PCI 64bit Resources Handling
Above 4G Decoding [Disabled]
PCI Common Settings
Load RT32 Image [Enabled]
PCI Express Settings
PCIE Slot Conguration
4.4.5 PCI Subsystem Settings
Allows you to configure PCI, PCI-X, and PCI Express Settings.
Above 4G Decoding [Disabled]
This item allows you to enable or disable 64-bit capable devices to be decoded
in above 4G Address Space if your system supports 64-bit PCI decoding.
Configuration Options: [Disabled][Enabled]
Load RT32 Image [Enabled]
Allows you to enable or disable the RT32 Image Loading. Configuration Options:
[Disabled][Enabled]
PCI Express Settings
Allows you to change the settings of the PCI Express Devices.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Set the ASPM Level: Force
L0s
- Force all links to L0s
State
: AUTO - BIOS auto
congure :DISABLE -
Disables ASM
PCI Express Device Register Setting
PCI Express Device Register Settings
ASPM Support [Disabled]
WARNING: Enabling ASPM may cause some
PCIE devices to fail
ASPM Support [Disabled]
This item allows you to enable or disable support to Active State Power
Management (ASPM). ASPM is a power management protocol that is used to
extend battey life. Configuration options:
[Disabled] Disables ASMP
[Auto] BIOS auto configure
[Force L0s] Force all links to L0s State

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
