ASUS TS110-E8-PI4
4-17
Compatible Mode [Disabled]
ThisitemonlyappearswhenyousettheSATAModeSelectionto[IDE].Thisitem
allowsyoutoenableordisabletheCompatiblemode.Congurationoptions:[Disabled]
[Enabled]
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [IDE]
Compatible Mode [Disabled]
S.M.A.R.T. Status Check [Enabled]
Serial SATA Port 0 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 1 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 2 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 3 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 4 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 5 ASUS DVD-E8 ATAPI
Software Preserve SUPPORTED
Determines how SATA
controller(s) operate.
4.4.4 System Agent (SA) Configuration
This allows you to change System Agent parameters.
VT-d [Enabled]
ThisallowsyouenableordisabletheVT-dfunctiononMCH.Congurationoptions:[Enabled]
[Disabled]
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Advanced
System Agent Bridge Name Haswell
System Agent RC Version 1.0.0.0
VT-d Capability Supported
VT-d [Enabled]
Enable NB Card [Disabled]
BDAT ACPI Table Support [Disabled]
VGA Priority [Offboard]
Memory Conguration
Check to enable VT-d
function on MCH.
Enable NB CRID [Disabled]
ThisallowsyouenableordisabletheNBCRIDWorkAround.Congurationoptions:
[Enabled][Disabled]
BDAT ACPI Table Support [Disabled]
ThisallowsyouenableordisablethesupportfortheBDATACPItable.Conguration
options:[Enabled][Disabled]
VGA Priority [Offboard]
This allows you to prioritize between the onboard and offboard video device to be found.
Congurationoptions:[Onboard][Offboard]
