ASUS TS110-E8-PI4
4-25
4.4.12 Onboard LAN Configuration
This allows you to change the enable or disable the onboard LAN.
INTEL I210 LAN1/LAN2 Enable [Enabled]
AllowsyoutoenableordisabletheINTELI210LANfunctioninthesystem.Conguration
Options:[Enabled][Disabled]
INTEL I210 LAN1/LAN2 OpROM [PXE]
AllowsyoutolaunchtheIntelI210LANOpROM.Congurationoptions:[Disabled][PXE]
[iSCSI]
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Advanced
INTEL I210 LAN
Disable/Enable
Onboard LAN Conguration
INTEL I210 LAN1 MAC: 00:E0:18:10:18:E8
INTEL I210 LAN2 MAC: 00:E0:18:10:18:E9
INTEL I210 LAN1 Enable [Enabled]
INTEL I210 LAN1 OpROM [PXE]
INTEL I210 LAN2 Enable [Enabled]
INTEL I210 LAN2 OpROM [PXE]
4.4.13 MIO Card Configuration
ThisitemallowsyoutosetMIOCardcongurationsettings.
MIO Card Type [ALC 892]
AllowsyoutoselecttheMIOcardtype.CongurationOptions:[ALC892][ALC888]
Front Panel Type [AC97]
Allows you to select the front Panel type of the MIO.
Congurationoptions:[AC97][HD]
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Advanced
MIO Card Type
Set MIO Card
MIO Card Type [ALC 892]
Front Panel Type [AC97]
