• Move the cursor to the action button Menu and press the enter key (2), following screen appears:
• Using the scroll keys (1), move the cursor to the test icon (see above, section Menu icon)
• Press the enter key (2), following screen appears:
Text on image
(1)
Test
(2)
Safety Valve Test
(3)
Not allowed
(4)
Audit Data
• The safety valve test can only be performed by authorized personnel and is protected by a security
code.
• Select the item display test and press the enter key. A screen is shown to inspect the display, at the
same time all LED's are lit.
4.17 User password menu
Menu icon, Password
Function
If the password option is activated, it is impossible for not authorized persons to modify any setting.
Procedure
Starting from the Main screen (see section Main screen),
• Move the cursor to Menu and press the Enter key (2). Following screen appears:
Instruction book
106 2920 7180 30
