5. Advanced operation
range. Such an extensive range is necessary to comply with the guidelines set forward by the latest
medical guidelines.
The available video encoding modes for your display are listed below.
Please note that the display controller connected to your display might not al ways sup-
port a ll these video encoding modes.
Standard
This mode uses the standard 8 bit encoding
mechanism.
HDR1
This mode features 10-bit video encoding following
the High Dynamic Range (HDR) standard, usually
used on color displays.
HDR2
HDR2 is a Barco specific mode featuring 10-bit
video encoding following the High Dynamic Range
(HDR) standard but allowing full refresh rate (which
is not always possible with HDR1). This mode is
usually used on color displays.
Dual 10 (only with Barco display controller) Dual 10 is a Barco specific 10-bit video encoding
mode which is usually used on grayscale displays
and which allows full refresh rate.
Automatic When selecting this option, your Coronis 3MP LED
Display will automatically assign the correct video
encoding settings to the connected video input
signals.
To manually select a video encoding mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source menu.
3. Enter the Video Encoding submenu.
4. Select one of the available video encoding modes and confirm.
5.22 G rayscal e conversio n modes
About grayscale conversion modes
Grayscale conversion modes specify how color generated on the display controller is converted to
grayscale in your display.
The available grayscale conversion modes are:
No Conversion
Use Red Channel This mode is intended for grayscale displays where
gray is sent over the red channel.
Use Green Channel This mode is intended for grayscale displays where
gray is sent over the green channel.
Use Blue Channel This mode is intended for grayscale displays where
gray is sent over the blue channel.
Use All Channels This mode is intended for grayscale displays where
gray is sent over the red, green and blue channel.
This is done by means of a standard conversion
mechanism where 30% red, 59% green and 11%
blue are used to generate gray.
30 K5902060 CORONIS 3MP LED DISPLAY 01/10/2015
