Barco Coronis Fusion 4MP Series User Manual

R5911227 /02 Coronis Fusion 4MP / 6MP32
2. Navigate to the Configuration > Image Sources menu.
3. Enter the Image Source Selection submenu.
4. Select the Automatic image source selection mode and confirm.
To manually select image sources:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources menu.
3. Enter the Image Source Selection submenu.
4. Select one of the following image source selection modes and confirm:
• One Image Source: Allows to select one image source to display.
• Two Image Sources: Displays DisplayPort IN 1 on the left side and DisplayPort IN 2 on the right side of
the screen.
• Expert mode: Allows to select for the left and right side of the screen which image source to display:
DisplayPort IN 1, DisplayPort IN 2 or None.
4.21 Grayscale conversion modes
Your Coronis Fusion 4MP / 6MP automatically detects the connected video input signals and
applies the correct grayscale conversion settings. Manually selecting a grayscale conversion mode
is possible, but then your display’s image source selection mode should be set to allow this. Refer to
“Image source selection”, page 31 to do this.
About grayscale conversion modes
Grayscale conversion modes specify how color generated on the display controller is converted to grayscale
in your display.
The available grayscale conversion modes are:
• No conversion
• Use Red Channel: This mode is intended for grayscale displays where gray is sent over the red channel.
• Use Green Channel: This mode is intended for grayscale displays where gray is sent over the green
channel.
• Use Blue Channel: This mode is intended for grayscale displays where gray is sent over the blue channel.
To manually select a grayscale conversion mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > Input Settings > DisplayPort 1/2 menu.
3. Enter the Grayscale Conversion submenu.
4. Select one of the available color conversion modes and confirm.
4.22 DisplayPort standard version
About DisplayPort standard version
The Coronis Fusion 4MP / 6MP supports 2 DisplayPort standard versions: DP V1.1 and DP V1.2
To select the DisplayPort standard version
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > Input Settings > DisplayPort1/2 menu.
Advanced operation
