Black Box ServSwitch User Manual

101
APPENDIX B: Cable Product Codes
Appendix B: Cable Product Codes
The table below and on the following pages lists the product codes for all the types
of cables we currently offer for use with the Matrix ServSwitch. The four digits that
follow the
dash in each product code indicate how long each cable is in feet
(one foot = 30.5 cm).
For most of these cables, xxx’s are shown in place of the last three digits of the
product code because the cables come in several stock lengths. For original
(standard) CPU and User cables, these last three digits can be “001” (User Cables
only), “005,” “010,” or “020” for 1-foot (0.3-m), 5-foot (1.5-m), 10-foot (3-m) or
20-foot (6.1-m) cables respectively. For coaxial cables, these last three digits can be
“005,” “010,” “020,” “035,” “050,” “075,” or “100” for 5-foot (1.5-m), 10-foot (3-m),
20-foot (6.1-m), 35-foot (10.7-m), 50-foot (15.2-m), 75-foot (22.9-m), or 100-foot
(30.5-m) cables respectively.
You’ll also see the product codes for the Station Extender and CAT5 KVM
Extender equipment listed at the end of this appendix.
Depending on your
equipment and the video resolution
you’re using, you might be able to use the
Extenders to connect the Matrix ServSwitch to a CPU or user station as much as
1000 ft. (300 m) away.
If your Matrix ServSwitch system has cabling requirements that can’t be met by
what you see here, call Black Box for a possible quote on custom cables or
adapters.
Standard User Cables:
Monitor Type Keyboard Type Mouse Type Product Code
(Connector on Cable) (Connector on Cable) (Connector on Cable)
VGA (HD15 female) IBM PC/AT (5-pin DIN female) Serial RS-232 (DB9 male) EHN052-0xxx
VGA (HD15 female) IBM PS/2 (6-pin mini-DIN female) PS/2 (6-pin mini-DIN female) EHN054B-0xxx
Multisync (HD15 female) Sun (8-pin mini-DIN female) N/A EHN059-0xxx
