MATRIX SERVSWITCH™
4. Full Configuration
Once your Matrix ServSwitch system is up and running, you can configure the
system from any attached user station (monitor, keyboard, and mouse). To do so,
press and release the left [Ctrl] key, then press the [F12] key to access the
configuration-menu screen shown in Figure 4-1. (After your initial access, if you’ve
set a configuration password, a text box prompts for it.) The configuration menu
displays on top of the currently connected computer’s screen if you are switched to
a computer with active video. If no computer is supplying video, the background is
black. If the display is not synchronized, switch to a computer with active video,
and change the on-screen display-resolution setting using the Configure KVM page
(see Section 4.4).
Figure 4-1. The configuration menu.
Matrix ServSwitch version MX16H Copyright 1990-2000
Configure password box numbers, keyboard settings, appearanc e
Main menu
Configure
System
Computer
KVM
User
Profile
Group
Status
Save
Exit
Use arrow keys to highlight
selection and press enter or
press escape to exit
