BLUM ZX-Speed User Manual

Mountingandcommissioning
322000010S|V1B|07/2017
10
©byBlum‐Novotest
4.1 Mountingvariants
4.1.1 Mountingvariantwithcable(outgoing)onside
NOTICE
Damagetomeasuringsystembylackingcablefixationpossible.
 Fixthespiral hosewithapipeclampascloseaspossibleonthedevice.
 Observetheminimumbendingradius,seechap.3.4.
NOTICE
Ifthecableislayedflexibly:
 Providesufficientstrainrelief .
 Limitthemovablepartofthespiralhosebypipeclamps.
Tochangeorremovethespiralhosebeforethemountingofthetouchprobe,bringthehose
nutonslightstrainandturnitcounterclockwise.
Fig.4‐1
(15) Hosenut
15
