BLUM ZX-Speed User Manual

Mountingandcommissioning
322000010S|V1B|07/2017
12
©byBlum‐Novotest
4.1.3 Mountingvarianthorizontal
Incaseofhorizontalmountingofthestylus,acoverwillbenecessary.
Makesurethatnochipspileupatthestylus.Dependingontheenvironmentalconditions,the
cleaningintervalisneededmorefrequently.
Fig.4‐4
4.1.4 Mountingvariantwithnozzle
Fig.4‐5
Installationinstructionofmountingsystem|nozzle
22
23
(22) P83.0175‐045.284
(23) P83.0175‐045.26x
